Request Artemis landers

[gattispilot]

SetEmptyMass(LMDesc_DRYMASS+ LMAsc_DRYMASS + LMAsc_FUELMASS + LMDesc_FUELMASS);
#define LMAsc_DRYMASS 10886.2 // kg 12 tons #define LMAsc_FUELMASS 6350.29 // kg 7 tons #define LMDesc_DRYMASS 23586.8 // kg 26 ton #define LMDesc_FUELMASS 20865.2 // kg 23 ton

I get 90 tons



[gattispilot]

This is a update with the updated masses,....
cpp file included.

Lots of things to do:
interior/vc she should have 4 MFD
cargo management
EVA
make the animation state carry to descent vessel. Once specs get correct then I will make a descent vessel module.

Right now the only animation that works is the gear "G". The elevator Pad "3" works but the initial rotation isn't working. neither is the pad up/down movement

on the cargo and EVA I am not sure to use UACS or make my own guys. There are 2 cargo holders that should animate down. Then just have cargo created there. May in place of 1 cargo have the FLEX?

On the dock. I believe position is correct not sure about orientation

FYI, going to be away for a week.



[francisdrake]

LMLander at the rim of the Ukert crater.

Could you please also provide the include file:
#include "LMLMESH.h"

LML::SetConfig0_stowed
Please delete the LMDesc_FUELMASS) from the dry mass calculation:
SetEmptyMass(LMDesc_DRYMASS+ LMAsc_DRYMASS + LMAsc_FUELMASS + LMDesc_FUELMASS);

I could land from orbit, as in the screenshot above, but had to 'refill' the fuel on the way down.



[gattispilot]

View attachment 36280
LMLander at the rim of the Ukert crater.

Could you please also provide the include file:
#include "LMLMESH.h"

LML::SetConfig0_stowed
Please delete the LMDesc_FUELMASS) from the dry mass calculation:
SetEmptyMass(LMDesc_DRYMASS+ LMAsc_DRYMASS + LMAsc_FUELMASS + LMDesc_FUELMASS);

I could land from orbit, as in the screenshot above, but had to 'refill' the fuel on the way down.

Updated the zip and cpp/module



[francisdrake]

Made a few proposed changes to the mass, thrust and ISP.
Details are in the Changelog-file. Modified cpp-file is included.

With these values the vessel can land from and return to low Lunar orbit.

Added a scenario to land from Lunar orbit near the Ukert crater.



[barrygolden]

hey yall might be time to look at doing the LTV or Lunar Terrian Vehicle



[gattispilot]

https://www.nasa.gov/wp-content/uploads/2020/06/draw_ltv_final-1.pdf

here is some drawings of it



[gattispilot]

Working on a VC for this guy. Sure I can make a mesh of the rover,....

I think I might add the cargoboxes that just move down to the terrain. They are attachments. The problem is I can have them as a vessel an attached. Make them a UACS cargo vessel and then have cargo deploy?



[barrygolden]

Keep in mind this thing would need to fold up somewhat like the LRV from Apollo



[gattispilot]

Keep in mind this thing would need to fold up somewhat like the LRV from Apollo

Not sure if that is possible.

Right now this lander has no vc, internal view. Trying to code that in



[barrygolden]

I know the LM lander needs a good VC you might look at this dark Matter VC for ideas
here is some examples of external cargo carrying the LTV would start out folded with the wheels underneath the tool boxes folded up into the seats and the light bar folded back. Covered with this gold foil then push a key and gold foil gone then another key and LTV on ground and deployed. I think the LM has 3 of these cargo racks 1 carry the rover another one carries the AlSEP and the third one carry the tool boxes



[gattispilot]

So far I got these. I need to add a middle section. Not sure how the seats should fit the guys. I will add the cargo section in the aft.



[barrygolden]

Really great start just to let you know those are the advanced Apollo EVA guys not the XEMU guys..
I think this LYV is to go on Artemis 5 but not set in stone



[gattispilot]

The guys were just to get the scale. Now I get this:



[barrygolden]

yes looking super and I know your going to add the rest of the stuff on top of the light bar



[gattispilot]

Yes.



[barrygolden]

way cool !!!



[Donamy]

I think it should have a canopy to keep out the moon dust.



[gattispilot]

I finally got the VC to load. But I am going to need help @Max-Q .
Something is weird. When in the left view I can't turn the middle MFD on and the left sel/mnu don't work. But switch to the right and I can operate the center and the left sel/mnu?

I need to paint the buttons also.

And then if this ever gets fixed. I will have to copy it for the ascent module, UGH



[gattispilot]

But I did get the LTV working?

I might need to add something? to the center part. Maybe a MFD?
