New Release D3D9Client Development

Face

Well-known member
Orbiter Contributor
Addon Developer
Beta Tester
Joined
Mar 18, 2008
Messages
4,390
Reaction score
577
Points
153
Location
Vienna
Was this https://www.orbiter-forum.com/threa...-sceneries-for-orbiter-2016.38022/post-571024 issue/vertical horizontal resolution issue ever resolved?
The 2016++ versions of Orbiter support vertical resolution of smaller than 1 meter. The above mentioned flattening also supports this now. As for the horizontal resolution, the documentation says level 17, but the code says that the maximum tile level loaded is 15. However - according to the code - a loaded elevation tile corresponds to a loaded texture tile level differently, presumably due to a great-grandfather relation. This would mean that level 15 is loaded by level 18+ texture levels, which would contradict the documentation.

Last edited:

dbeachy1

O-F Administrator
Administrator
Orbiter Contributor
Addon Developer
Donator
Beta Tester
Joined
Jan 14, 2008
Messages
9,214
Reaction score
1,560
Points
203
Location
VA
Website
alteaaerospace.com
Preferred Pronouns
he/him
Are there any configuration steps necessary in order to build the D3D9 client using CMake? What I did was:

  1. Clone that latest D3D9 repo to a new folder: git clone [email protected]:jarmonik/D3D9Client.git
  2. Run "C:\Program Files (x86)\Microsoft Visual Studio\2019\Community\VC\Auxiliary\Build\vcvars32.bat" to initialize the VS 2019 command-line build environment.
  3. CD D3D9Client
  4. cmake .
Here is the console output:

Code:
D:\GitHub\D3D9Client>cmake .
-- Building for: Visual Studio 16 2019
-- Selecting Windows SDK version 10.0.19041.0 to target Windows 10.0.19043.
-- The C compiler identification is MSVC 19.29.30040.0
-- The CXX compiler identification is MSVC 19.29.30040.0
-- Detecting C compiler ABI info
-- Detecting C compiler ABI info - done
-- Check for working C compiler: C:/Program Files (x86)/Microsoft Visual Studio/2019/Community/VC/Tools/MSVC/14.29.30037/bin/Hostx64/x64/cl.exe - skipped
-- Detecting C compile features
-- Detecting C compile features - done
-- Detecting CXX compiler ABI info
-- Detecting CXX compiler ABI info - done
-- Check for working CXX compiler: C:/Program Files (x86)/Microsoft Visual Studio/2019/Community/VC/Tools/MSVC/14.29.30037/bin/Hostx64/x64/cl.exe - skipped
-- Detecting CXX compile features
-- Detecting CXX compile features - done

...but then CMake hangs forever, with Task Manager showing CMake using 100% of a single core, so looks like it's stuck in a loop?

I also tried building D3D9 from inside VS 2019 via D3D9Client\Orbitersdk\D3D9Client\D3D9ClientVS2019.sln and then doing a Rebuild All for the win32 target, but the build fails with:

Rebuild started...
1>------ Rebuild All started: Project: D3D9Client, Configuration: Debug Win32 ------
1>D:\GitHub\D3D9Client\Orbitersdk\D3D9Client\D3D9ClientVS2019.vcxproj(39,5): error MSB4019: The imported project "D:\GitHub\D3D9Client\Orbitersdk\VS2015\PropertyPages\orbiter_plugin.props" was not found. Confirm that the expression in the Import declaration "D:\GitHub\D3D9Client\Orbitersdk\D3D9Client\..\VS2015\PropertyPages\orbiter_plugin.props" is correct, and that the file exists on disk.
1>Done building project "D3D9ClientVS2019.vcxproj" -- FAILED.
========== Rebuild All: 0 succeeded, 1 failed, 0 skipped ==========

Am I missing some steps?


kuddel

Donator
Donator
Joined
Apr 1, 2008
Messages
2,064
Reaction score
507
Points
113
Hey you git-experts out there:
As Jarmo moved the D3D9Client repository to git (including history ? ), is there a way to convert/change the subversion-authors afterwards?
I mean there were some contributors :
Code:
Felix24 => ???
jarmonik => jarmonik @ git
Jarmonik => jarmonik@ git
Kuddel => schnepe2@ git
kuddel => schnepe2@ git
solarliner => ???
xyon => ????
...hehe from the "case-sensitiveness" I can even say from what machine I committed :D Jarmo, too it seems
Authors.png Authors2.png

Last edited:

Face

Well-known member
Orbiter Contributor
Addon Developer
Beta Tester
Joined
Mar 18, 2008
Messages
4,390
Reaction score
577
Points
153
Location
Vienna
Yes. You can convert a git repo to another while filtering branches, data, or even remap meta-data. However, it is history rewriting, and will produce commits with different hashes.

EDIT: just found out that it already has a feature especially for this use-case: https://git-scm.com/docs/gitmailmap

Last edited:

kuddel

Donator
Donator
Joined
Apr 1, 2008
Messages
2,064
Reaction score
507
Points
113
[...]However, it is history rewriting, and will produce commits with different hashes.
Would that be a problem? I mean now in this early state we should do this - as it would become worse later on I assume.
Deleting my fork and forking again from the new repository is not an issue, now. I have not yet done too much locally ;)


Face

Well-known member
Orbiter Contributor
Addon Developer
Beta Tester
Joined
Mar 18, 2008
Messages
4,390
Reaction score
577
Points
153
Location
Vienna
Would that be a problem? I mean now in this early state we should do this - as it would become worse later on I assume.
Deleting my fork and forking again from the new repository is not an issue, now. I have not yet done too much locally ;)
Indeed, the classic rewrite approach would be a problem later on, but the mail map approach is much less invasive, as it basically uses a checked in file to remap the author names at the user end, not in the repo data itself.


kuddel

Donator
Donator
Joined
Apr 1, 2008
Messages
2,064
Reaction score
507
Points
113
Ah! I remember I have read that some time ago (that's why I have a authors.map file laying around on my disk ;) )
That includes e-mail addresses (of jarmo an me)...I guess we have to get permission from each one of them to include that data, right?


Face

Well-known member
Orbiter Contributor
Addon Developer
Beta Tester
Joined
Mar 18, 2008
Messages
4,390
Reaction score
577
Points
153
Location
Vienna
An example to fix up the various Jarmo entries, you can create a ".mailmap" file in the repo root like so:
Code:
jarmonik <proper@mail> <jarmonik@c0f5cd98-1510-604a-8459-bf7538b8c9c2>
jarmonik <proper@mail> <[email protected]>

"git shortlog -sne" will then return:
Code:
   471  Kuddel <Kuddel@c0f5cd98-1510-604a-8459-bf7538b8c9c2>
   461  jarmonik <proper@mail>
    44  kuddel <kuddel@c0f5cd98-1510-604a-8459-bf7538b8c9c2>
     2  face <proper@mail>
     2  xyon <xyon@c0f5cd98-1510-604a-8459-bf7538b8c9c2>
     1  Felix24 <Felix24@c0f5cd98-1510-604a-8459-bf7538b8c9c2>

EDIT: obfuscated real emails a bit, the SVN thingies are BS, anyway.


kuddel

Donator
Donator
Joined
Apr 1, 2008
Messages
2,064
Reaction score
507
Points
113
Hmm I have to let that sink in a little bit ....

What makes me wonder is github again, should I add the "github noreply email", too?
...And is that the one I can find at "Account settings" -> "Emails" -> "Keep my email addresses private"?
...And do I have to check that checkbox there?

On github my name should be displayed as 'schnepe2' I guess, as 'kuddel' is someone else on github.

We might skip this to a time when we have nothing else to do ;)
Thanks again for the insights!


kuddel

Donator
Donator
Joined
Apr 1, 2008
Messages
2,064
Reaction score
507
Points
113
@jarmonik : To give me a break from fighting git(hub), I stepped back a bit and took a look at the D3D9Client sample add-ons.
GenericCamera MFD & DX9ExtMFD made heavy use of gcAPI, which has been removed from the git repository.
What is the plan with that API? Is the plan to add those to Orbiter API?
Orbiter (git) has not yet received changes for those, right?


jarmonik

Well-known member
Orbiter Contributor
Addon Developer
Beta Tester
Joined
Mar 28, 2008
Messages
2,651
Reaction score
785
Points
128
@jarmonik : To give me a break from fighting git(hub), I stepped back a bit and took a look at the D3D9Client sample add-ons.
GenericCamera MFD & DX9ExtMFD made heavy use of gcAPI, which has been removed from the git repository.
What is the plan with that API? Is the plan to add those to Orbiter API?
Orbiter (git) has not yet received changes for those, right?
The old and obsolete gcAPI has been removed but the newer gcCore API remains. And those projects are already converted to use the gcCore.

It's likely that the Sketchpad2 &3 would need to be integrated to the Orbiter's Sketchpad interface. But is's too early to say much about the gcCore integration, probably not.


jarmonik

Well-known member
Orbiter Contributor
Addon Developer
Beta Tester
Joined
Mar 28, 2008
Messages
2,651
Reaction score
785
Points
128
Are there any configuration steps necessary in order to build the D3D9 client using CMake? What I did was:
I have used the cmake-gui (graphical interface) which seems to work fine. I tried that "cmake ." from command line and it jammed just like you said. From where does it get the platform options, source and binary directories ? If the source and binary directories are the same then "copy folder" might end-up in a loop but that's just a wild guess.


jarmonik

Well-known member
Orbiter Contributor
Addon Developer
Beta Tester
Joined
Mar 28, 2008
Messages
2,651
Reaction score
785
Points
128
Hey you git-experts out there:
As Jarmo moved the D3D9Client repository to git (including history ? ), is there a way to convert/change the subversion-authors afterwards?
Yeah, it would be nice to get that sorted out. Some of those user names might be from the CodePlex times.


martins

Orbiter Founder
Orbiter Founder
Joined
Mar 31, 2008
Messages
2,448
Reaction score
462
Points
83
Website
orbit.medphys.ucl.ac.uk
I am trying to build the D3D9Client (64-bit) from the github repo (jarmonik/D3D9Client), but I am running into a problem

undeclared identifier 'gCameraPos' (in Common.hlsl)
Cannot open include file: 'gcAPI.h': No such file or directory (in MFDWindow.h and MFD.h)

gcAPI has been mentioned above, so I guess this is a known issue? Should I wait before trying to compile D3D9Client myself?


jarmonik

Well-known member
Orbiter Contributor
Addon Developer
Beta Tester
Joined
Mar 28, 2008
Messages
2,651
Reaction score
785
Points
128
I am trying to build the D3D9Client (64-bit) from the github repo (jarmonik/D3D9Client), but I am running into a problem

I have committed a fix that removes the dependency to gcAPI.h (something that I didn't notice earlier). For the other problem I have simply selected "does not participate in build" as shown in the screen shot. Those files are compiled during D3D9Client startup.


Attachments

  • build.png
    124.7 KB · Views: 13

kuddel

Donator
Donator
Joined
Apr 1, 2008
Messages
2,064
Reaction score
507
Points
113
Is this declaration/definition in CMakeLists.txt O.K. this way?
Makefile:
set(DXSDK_DIR "C:/Program Files (x86)/Microsoft DirectX SDK (June 2010)")

I mean: The Visual-Studio-Projects 'till now assumed the environment variable DXSDK_DIR to be set to the correct location on a build machine.
I for example have one machine where the path differs:
Rich (BB code):
c:\>set
ALLUSERSPROFILE=C:\ProgramData
...
DXSDK_DIR=C:\Program Files (x86)\Microsoft SDKs\DirectX (June 2010)\
...
That's why I only referenced $(DXSDK_DIR) in the project files.

Is there something like (Note: NOT actual CMake syntax I believe ;) ):
Makefile:
if not set environment(DXSDK_DIR)
  set(DXSDK_DIR "C:/Program Files (x86)/Microsoft DirectX SDK (June 2010)") # default if not proper set in environment

# or

set(DXSDK_DIR extractFromEnvironmentOrDefault("%DXSDK_DIR%"  "C:/Program Files (x86)/Microsoft DirectX SDK (June 2010)"))

Last edited:

kuddel

Donator
Donator
Joined
Apr 1, 2008
Messages
2,064
Reaction score
507
Points
113
From searching the net I would guess something like this can do the job (although I have no idea what that CACHE INTERNAL thing is ;)
Makefile:
if (NOT "$ENV{DXSDK_DIR}" STREQUAL "")
    set(DXSDK_DIR)"$ENV{DXSDK_DIR}" CACHE INTERNAL "Copied from environment variable")
else()
    set(DXSDK_DIR "C:/Program Files (x86)/Microsoft DirectX SDK (June 2010)")
endif()


dbeachy1

O-F Administrator
Administrator
Orbiter Contributor
Addon Developer
Donator
Beta Tester
Joined
Jan 14, 2008
Messages
9,214
Reaction score
1,560
Points
203
Location
VA
Website
alteaaerospace.com
Preferred Pronouns
he/him
I have used the cmake-gui (graphical interface) which seems to work fine. I tried that "cmake ." from command line and it jammed just like you said. From where does it get the platform options, source and binary directories ? If the source and binary directories are the same then "copy folder" might end-up in a loop but that's just a wild guess.

So you were right -- CMake from the command line did end up in a copy loop of some sort: I wanted to delete my D3D9Client folder today, and got an error from the path being too deep. It turns out CMake from the command line created a (very very long) path like this:

Code:
D3D9Client\Orbitersdk\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\doc\...

I couldn't delete the tree with Windows, but I was able to finally delete it via rm -rf from Cygwin. I'll try building it with cmake-gui instead of the command line.


jarmonik

Well-known member
Orbiter Contributor
Addon Developer
Beta Tester
Joined
Mar 28, 2008
Messages
2,651
Reaction score
785
Points
128
So you were right -- CMake from the command line did end up in a copy loop of some sort: I wanted to delete my D3D9Client folder today, and got an error from the path being too deep. It turns out CMake from the command line created a (very very long) path like this:
That problem should be fixed. I also had some difficulties deleting that. It's odd that there's no loop protection in CMake to prevent cases like this.
